National Instruments CAL-4309 DC Offset Calibration Accessory
The CAL-4309 (Part Number: 784958-01) is a specialty calibration accessory for the PXIe-4309 analog input module. This precision accessory has a high-quality banana plug connection to the input channels of the module, enabling automatic verification of DC offset. Engineers and calibration technicians can be assured of the accuracy of the DC measurements of the PXIe-4309, while eliminating the manual intervention process, saving time and guaranteeing performance standards that are traceable to test systems across multiple data acquisitions.
The CAL-4309 will be used in laboratories and production operations where accessory measurements of analog signals are necessary for the systematic handling of performance of voltages of this high accuracy. With this accessory connected to the PXIe-4309, it will generate accurate voltages that the PXIe-4309 module uses for self-verifying its DC performance of offset from the normal. The process of automatic adjustment of the process of normal operation to retain its offset position will allow the analog input channels to maintain the calibration performance over time. This is essential for sensor characterization, industrial monitoring, and precision measurement systems.
Integrating the CAL-4309 with the PXI measurement system will eliminate man-hours associated with the re-calibration of the instrument. The accessory can be accommodated in all of the auto-calibration scripts associated with systems within the NI software group. Offset checks are thus continuously performed and repeatedly executed in the standard, short time frame of calibration time in normal industrial settings. The structure of the accessory will permit very crude input connections, but nevertheless retain their continued use in the study of instrument failure under simulated long-term usage.
The CAL-4309 is used with the PXIe-4309 for supplying up to 32 full advantages of received input channels that have the flexibility of 18 to 28 bits of resolution. This accessory is designed in a particular way to help retain that fidelity in measurement that is characteristic of the performance of the PXIe-4309. This calibration accessory is one important facet for retaining the reliability and accuracy of PXI-type data acquisition systems, measured with full gauge of confidence in every instance of reading of all voltages associated there with, as they all meet performance rigidly required by the standards of metrology.
| Model Name | CAL-4309 |
|---|---|
| Part Number | 784958-01 |
| Part Type | Calibration Accessory |
| Compatible Module | PXIe-4309 |
| Interface | Banana Plug |
| Measurement Type | DC Voltage |
| Platform | NI PXI/PXIe |
| Manufacturer | National Instruments |
| Warranty | 2-3 Year Warranty |
| Pricing | Request a Quote Today for Pricing! |
