NI 782290-01 Desktop Power Supply
Designed for Basler Ace Camera Link Cameras, part number 782290-01 is a 12V/2A Desktop Power Supply. This Desktop Power Supply comes with a 4-pin M5 connector on the camera end and a C14 jack connector on the mains power supply side. The camera power cable used with this Power Supply measures around 2 meters in length. Part number 782290-01 Desktop Power Supply is fully compatible with multiple Camera Link Cameras from Basler.
This Power Supply can be operated over an inlet voltage of 90 V – 264 V and frequency range of 47 - 63 Hz. The rated DC output voltage of this Desktop Power Supply is 12 VDC ± 1 %. The inputs and outputs have isolation between them. Part number 782290-01 comes featured with various safety and protective features, including LPS, overvoltage, and short circuit. This Desktop Power Supply is built in accordance with the requirements of RoHS, CE, and UL.
| Model | 782290-01 |
|---|---|
| Manufacturer | NI |
| Type | Power Supply |
| Compatible Models | Basler Ace Camera Link Cameras |
| Mounting Type | Desktop |
| Maximum Voltage | 12 V |
| Maximum Current | 2 A |
| Warranty | 2-3 Year Warranty |
| 782290-01 Manual | User Manual and Maintenance Manual Available for Download |
| Pricing | Contact a Sales Representative for a quote. |
