Spirent SmartBits SMB-6000B Performance Analysis System
The SmartBits SMB-6000B, an excellent network performance analysis system, is a product of Spirent Communications. Particularly designed to utilize an enormous number of ports, the Spirent SmartBits SMB-6000B is a high-class performance analysis device with the highest port density in the Spirent SmartBits products. The chassis of the Spirent SmartBits SMB-6000B test system is dynamically designed to support 24 conventional GbE ports, 06 10GbE ports, up to 96 10/100 Mbps Ethernet ports, 24 Fiber channel ports, or a combination of all ports.
The Spirent SmartBits SMB-6000B chassis can connect up to 12 modules to achieve the highest port density. The auto-controlled large-scale testing in production and quality control industrial activities can be carried out by using customized stacked units of the Spirent SmartBits SMB-6000B units. The Spirent SmartBits SMB-6000B chassis units can be interconnected together to form up to 512 chassis synchronized network to perform large-scale testing and monitoring operations. Within the chassis of the Spirent SmartBits SMB-6000B test system, an optional accessory LockBar is provided to ensure the security of the modules housed in the chassis.
The Spirent SmartBits SMB-6000B test system is a user-oriented chassis with the feature of multi-user operation. The control of the Spirent SmartBits SMB-6000B test system can be done by a local Windows OS-based PC through a 10/100 Mbps Ethernet connection. The applications of the SmartBits SMB-6000B test system are in the equipment manufacturing units, evaluation labs, and enterprise users. From performance analysis to verification and certification of the equipment performance, the Spirent SmartBits SMB-6000B chassis is used in a wide range of industrial applications with promising results.
| Model | SMB-6000B |
|---|---|
| Manufacturer | Spirent Communications |
| Type | High-Density Network Performance Analysis System |
| Module Capacity | 12 |
| Ethernet Connection | 10/100 Mbps |
| Max. GbE Ports | 24 |
| Max. 10 GbE Ports | 6 |
| Max. 10/100 Mbps Ethernet Ports | 96 |
| Max. POS Ports | 24 |
| Max. Fiber Channel Ports | 24 |
| Max. Daisy-chained Chassis | 512 |
| Operating Temperature | 15 degrees C to 40 degrees C |
| Warranty | 2-3 Year Warranty |
| SMB-6000B User Manual | User Manual and Maintenance Manual Available for Download |
| Price | Contact a sales representative for a quote. |
