Spirent SmartBits POS-3511A TeraMetrics Module
The SmartBits POS-3511A is an efficient and customizable OC-3c/OC-12c TeraMetrics Module. The manufacturing of the SmartBits POS-3511A TeraMetrics Module is done by Spirent Communications. Able to perform full-scale testing of Packet over SONET (POS) and SDH systems, the SmartBits POS-3511A TeraMetrics Module simulates millions of control protocols in the process of testing. The SmartBits POS-3511A TeraMetrics module is designed to work with the Spirent SmartBits SMB-600 and SMB-6000B performance monitoring system/chassis for testing of POS/SDH routers with frame-level precision in generation and analysis. The evaluation, comparison, quality assessment, and validation of the POS routers are a few among the basic and outstanding features of the SmartBits POS-3511A module.
The Spirent SmartBits POS-3511A module supports a line rate of 155 Mbps in OC-3c and a line rate of 622 Mbps in OC-12c applications. Equipped with 2 ports on the interface, the SmartBits POS-3511A module can perform stream-based analysis and generation efficiently. The generation of peer-to-peer streams up to a maximum number of 512 and analysis up to a maximum number of 64K streams at any instant can be done by the SmartBits POS-3511A TeraMetrics module. The frame length range supportable by the SmartBits POS-3511A TeraMetrics Module is 42 bytes – 16384 bytes.
The Spirent SmartBits POS-3511A module supports a frame size range of 8 to 16384 bytes in Capture Mode. Each port of the Spirent SmartBits POS-3511A TeraMetrics Module is featured with a capture buffer memory of 16 MB. The Spirent SmartBits POS-3511A TeraMetrics Module possesses a 1300 nm wavelength interface. In the multimode operation, the reach of the Spirent SmartBits POS-3511A module is up to 500 meters. The Spirent SmartBits POS-3511A TeraMetrics Module is compatible with Windows OS.
| Model | POS-3511A |
|---|---|
| Manufacturer | Spirent Communications |
| Type | OC-3c/OC-12c TeraMetrics Module |
| Compatible Chassis | SMB-600 and SMB-6000B |
| Number of Ports | 2 |
| Laser Wavelength | 1300 nm |
| Line Speed | 155 Mbps (OC-3c) , 622 Mbps (OC-12c) |
| Transmission Frame Size | 42 – 16,384 bytes |
| Capture Frame Size | 8 – 16,384 bytes |
| Capture Frame Size | 16 MB |
| Reach | 500 Meters |
| Warranty | 2-3 Year Warranty |
| POS-3511A User Manual | User Manual and Maintenance Manual Available for Download |
| Price | Contact a sales representative for a quote. |
