Spirent SmartBits POS-3504AS OC-48c ATM SmartMetrics Module
The SmartBits POS-3504AS is a promising OC-48c ATM Module. The SmartBits POS-3504AS ATM Module is a product of Spirent Communications. Designed to work with the Spirent SmartBits SMB-600 and SMB-6000B, the SmartBits POS-3504AS ATM Module is a powerful tool for the testing of Synchronous Digital Hierarchy (SDH) systems and Packet over Synchronous Optical Network (SONET) systems. The configuration and control of the SmartBits POS-3504AS module are done by a PC with Windows operating system installed.
The Spirent SmartBits POS-3504AS ATM Module comes with a single-mode port. The laser wavelength featured in the SmartBits POS-3504AS module is 1310 nm. The line rate of 2.488 Gbps is supported by the SmartBits POS-3504As module with a framing genre of OC-48c for SONET and STM-16 for SDH. At any instant, the SmartBits POS-3504AS ATM Module can generate 512 peer-to-peer IP streams and evaluating 21,845 streams. Moreover, the Spirent SmartBits POS-3504AS ATM OC-48c Module can support 42 – 16384 bytes of frame size. With these outstanding features, the Spirent SmartBits POS-3504AS module is used to measure latency, the capacity of loads, and many other essential parameters in the testing of internet devices.
The Spirent SmartBits POS-3504AS ATM Module has a reach in the range of 2 to 15 Km in testing applications. Hundreds of thousands of client and server internet sessions can be realistically simulated by using the SmartBits POS-3504AS module. This is possible due to the scalable characteristics of the SmartBits POS-3504AS module. The Spirent SmartBits POS-3504AS ATM Module is developed with frame-based transmission and receiving features. In the capture mode of the Spirent SmartBits POS-3504AS ATM Module, the supported frame length is in the range of 9 to 16384 bytes.
| Model | POS-3504AS |
|---|---|
| Manufacturer | Spirent Communications |
| Type | OC-48c ATM SmartMetrics Module |
| Compatible Chassis | SMB-600 and SMB-6000B |
| Number of Ports | 1 |
| Mode | Single Mode |
| Laser Wavelength | 1310 nm |
| Line Speed | 2.488 Gbps |
| Transmission Frame Size | 42 – 16,384 bytes |
| Capture Frame Size | 9 – 16,384 bytes |
| Reach | 2 – 15 Km |
| Warranty | 2-3 Year Warranty |
| POS-3504AS User Manual | User Manual and Maintenance Manual Available for Download |
| Price | Contact a sales representative for a quote. |
