Spirent SmartBits LAN-3200A Gigabit Ethernet Module
The SmartBits LAN-3200A is an Ethernet SmartCard Module. The SmartBits LAN-3200A Ethernet Module is launched by Spirent Communications. The Spirent SmartBits LAN-3200A Ethernet Module contains 2 ports of the 1000Base-SX standard. The SmartBits LAN-3200A module is inserted in one slot of either SMB-600 or SMB-6000B Performance Analyzer Chassis to use in industrial applications. The applications of the SmartBits LAN-3200A module in industries cover the generation and capture of data flow in the network systems with enhanced accuracy and precision. In addition to the data generation and capture, the SmartBits LAN-3200A module can also monitor the data flow in Ethernet traffic.
The SmartBits LAN-3200A module features the interface of multimode fiber type having a wavelength of 850 nm. Capable of supporting a speed of 1 Gbps in full-duplex mode with the cycle redundancy check (CRC) error detection feature, the SmartBits LAN-3200A module stands out as a smart choice to produce, transmit, and receive the Ethernet traffic at a speed more than the rated wire rate. The SmartBits LAN-3200A module is deployed in the industries to test the data throughput of the communication systems. This is attained when SmartBits LAN-3200A module is integrated with the Spirent LAN-3100A module.
The SmartBits LAN-3200A module can capture a buffer size up to 128 KB. The packet length range compatible with the SmartBits LAN-3200A Gigabit Module is 32 – 2048 bytes. The IPG adjustment resolution of the SmartBits LAN-3200A module is 32 ns. In conformance with the IEEE standard specification 802.3z, the SmartBits LAN-3200A SmartCard Module can be used to evaluate the parameters of mutually integrated Gigabit Ethernet devices in a network.
| Model | LAN-3200A |
|---|---|
| Manufacturer | Spirent Communications |
| Type | Ethernet SmartCard |
| Number of Ports | 2 |
| Compatible Chassis | SMB-600 and SMB-6000B |
| Duplex Operation | Full |
| Line Rate | 1 Gbps |
| Interface Type | Multimode Fiber |
| Laser Wavelength | 850 nm |
| Packet Length | 32 – 2,048 bytes |
| Warranty | 2-3 Year Warranty |
| LAN-3200A User Manual | User Manual and Maintenance Manual Available for Download |
| Price | Contact a sales representative for a quote. |
