Spirent SmartBits AT-9034B ATM E3 Module
The SmartBits AT-9034B is an ATM E3 Module. The SmartBits AT-9034B ATM E3 Module is manufactured by Spirent Communications. The Spirent SmartBits AT-9034B module is provided with a single port on its connection panel. Introduced particularly for the ATM traffic, the SmartBits AT-9034B module is applied to the networks containing interconnected formations of ATM, LAN, xDSL, and edge devices. Moreover, the ATM to ATM network traffic is also an application niche of the SmartBits AT-9034B module. In addition to the abovementioned areas, the SmartBits AT-9034B is also deployed in the virtual circuits and Smart Signaling areas with a guarantee of a high level of correctness and precision.
The Spirent SmartBits AT-9034B SmartCard ensures promising results in the generation of frames and measurement of parameters in ATM networks. In Smart Signaling, the highest value of the call rate can be conveniently measured with the help of the SmartBits AT-9034B module. Moreover, the configuration of latency settings in switched virtual circuits is done by the SmartBits AT-9034B module. Utilizing a 40-port ATM test suite, the SmartBits AT-9034B supports up to 32000 calls per second in Smart Signaling with each port supporting 800 calls in each second.
The Spirent SmartBits AT-9034B ATM SmartCard efficiently analyzes the end-to-end performance of the networks having multiple xDSL devices installed. In the virtual circuit applications, the capability of the Spirent SmartBits AT-9034B module is up to 2048 frames generation. The similar number of Point-to-Point Protocol (PPP) sessions can be simulated by the Spirent SmartBits AT-9034B ATM SmartCard while performing PPP testing and analysis. The Spirent SmartBits AT-9034B ATM SmartCard is well-suited for multiple Spirent SmartBits devices to accomplish a thorough full-duplex frame-level testing of network components.
| Model | AT-9034B |
|---|---|
| Manufacturer | Spirent Communications |
| Type | ATM E3 SmartCard |
| Number of Ports | 1 |
| Max. Frames Generation | 2,048 |
| Max. PPP Sessions | 2,048 |
| Max. LECs | 64 |
| Max. Calls per Port per Second | 800 |
| Max. VCCs per Port | 8.38 Million |
| Weight | 3 lbs. |
| Warranty | 2-3 Year Warranty |
| AT-9034B User Manual | User Manual and Maintenance Manual Available for Download |
| Price | Contact a sales representative for a quote. |
