National Instruments USRP-2930 USRP Software-Defined Radio Device

The USRP-2930 is a USRP Software Defined Radio Device. National Instruments developed the NI USRP-2930 device. The USRP-2930 is shipped with part number 781910-01. The NI USRP-2930 comes belongs to the USRP-293x modules by National Instruments. The NI USRP-2930 device is manufactured with an Oven Controlled Crystal Oscillator (OCXO) and can be used with GPS global services. The NI USRP-2930 is evaluated with 20 MHz bandwidth.

The National Instruments USRP-2930 USRP Software Defined Radio Device is operated with an RF transceiver that can be tuned on the multiple frequencies. The receiver of the NI USRP-2930 contains an ADC converter that utilizes 2 channels with 14-bit resolution. The USRP-2930 has a sampling rate of 100 MS/s. The transmitter of the NI USRP-2930 device is comprised of 2 channels that work with 16-bit resolution. The USRP-2930 consists of a DAC converter with an update rate of 400 MS/s. The NI USRP-2930 can be used for the ISM frequency band transceiver.

The USRP-2930 is activated with an Ethernet Bus connector. The NI USRP-2930 provides streaming for I and Q baseband signals. The Ethernet bus has a size of one Gigabit. The USRP-2930 device can be used for spectrums and Wi-Fi communication applications. The industrial and Wi-Max applications are used with the NI USRP-2930. The frequency range of 50 MHz to 2.2 GHz is used for the streaming of RF signals for the USRP-2930. The NI USRP-2930 device is used with a maximum power supply of 18 Watts.

ModelUSRP-2930
ManufacturerNational Instruments
Part Number781910-01
TypeUSRP Software Defined Radio Device
Input Channels1
Output Channels1
RF Frequency Range50 MHz to 2.2 GHz
Bus ConnectorEthernet
Dimensions6.25 in. × 1.9 in. × 8.35 in.
Weight2.63 lb.
Warranty2-3 Year Warranty
USRP-2930 ManualUser Manual and Maintenance Manual Available for Download
PriceContact a sales representative for a quote.

Associated part numbers for USRP-2930:
