National Instruments USRP-2900 Software Defined Radio Device
The USRP-2900 is a USRP Software Defined Radio Device. The NI USRP-2900 device is manufactured by National Instruments. The USRP-2900 is made by National Instruments with part number 784039-01. The NI USRP-2900 supports USB 2.0 and USB 3.0 connectivity. The USRP-2900 device is particularly developed for various portable applications to serve communication purposes; therefore, it is offered with a bus-powered USB connection. The applications of the USRP-2900 device include, but are not limited to, broadcast frequency modulation (FM) systems, global positioning systems (GPS), sensor networks, and common commercial safety systems.
The NI USRP-2900 device is a transceiver which can be tuned as per requirements for a wide range of operations. The USRP-2900 USRP Software Defined Radio Device comes with the NI-USRP software tool through which this device can be tuned for full-duplex operation. The NI USRP-2900 contains 1 input and 1 output channel. The USRP-2900 is compatible with the radio frequency (RF) in the range of 70 MHz to 6 GHz. The maximum input power of the receiver is -15 dBm and the maximum output power of the transmitter is 20 dBm. The NI USRP-2900 transceiver shows a frequency accuracy of 2.5 ppm in either mode of the transceiver; these modes are transmission and receiving. The instantaneous bandwidth of the USRP-2900 transceiver is 56 MHz. The NI USRP-2900 transceiver features an analog to digital (ADC) and digital to analog (DAC) resolution of 12 bits.
The USRP-2900 transceiver is designed according to the safety standards IEC 61010-1, EN 61010-1. The NI USRP-2900 transceiver requires up to 4.5 W power for operation and is compatible with a 6 V, 3 A external power supply.
| Model | USRP-2900 |
|---|---|
| Manufacturer | National Instruments |
| Part Number | 784039-01 |
| Type | USRP Software Defined Radio Device |
| Input Channels | 1 |
| Output Channels | 1 |
| RF Frequency Range | 70 MHz to 6 GHz |
| Bus Connector | USB 2.0, USB 3.0 |
| Dimensions | 7.0 in. × 4.9 in. × 1.5 in. |
| Weight | 1.5 lb. |
| Warranty | 2-3 Year Warranty |
| USRP-2900 Manual | User Manual and Maintenance Manual Available for Download |
| Price | Contact a sales representative for a quote. |
Associated part numbers for USRP-2900:
USRP-2900 PDF Manuals
NI-USRP-29002901-LETTER-OF-VOLATILITY.PDF
USRP-2900-2901-GETTING-STARTED-GUIDE.PDF
USRP-2900-SAFETY-ENVIRONMENTAL-AND-REGULATORY-INFORMATION.PDF
