National Instruments PCI-8516 LIN Interface Device
The PCI-8516 (Part Number: 781365-01) is a PCI-bus interface board intended for soft-motion controls. This model offers 6 channels, the most developed encoder interface, 16 bits D/A yield, and position mode servo drive or stepper drive for soft-motion controls. For processing up to 5MHZ A, B stage signals, both the encoder and the D/An interface are separated from the servo drive with broken or short wires being identified together with multi-stage advanced channels. Other propelled highlights offered by this model are subcount for low speed feedback, watchdog or encoder wire failure alert interferes with, record and general computerized inputs hinder with position locks, position examination and hinders for advanced CAM, even double enlistment capacities for printing together make it the best movement interface board ever.
Controller zone systems are utilized in the NI PCI-8516 as a part of a wide assortment of installed applications extending from small medical gadgets to huge earth-moving gear. To best exploit the cost and execution of CAN over these distinctive applications while keeping up programming and useful similarity for apparatuses, the user can utilize an assortment of physical layers improved for various benchmarks. The physical layer of a CAN usage directs the cabling writes, electrical signal levels, and termination scheme used. The segment of a CAN interface that associates a CAN controller to the system is known as a transceiver.
The PCI-8516 comes with 2-port fast LIN interface (20 kbit/s per port) with locally available ATA6620 transceivers, NI-XNET driver for creating edge and signal applications in LabVIEW, LabWindows™/CVI, and C/C++, and NI-XNET gadget driven DMA motor couples the LIN transport to have memory to limit message inactivity.
| Model | PCI-8516 |
|---|---|
| Manufacturer | National Instruments |
| Part Number | 781365-01 |
| Type | LIN Interface Device |
| Ports | 2 |
| Transceiver | ATMEL ATA6620 |
| Bus | LIN |
| Physical Layer | LIN |
| Maximum Baud Rate | 20 kbits/s |
| Minimum Baud Rate | 2400 bits/s |
| Trigger Lines | 7 Input/Output |
| Clock Lines | 1 Input/Output |
| I/O Compatibility | TTL |
| Operating Temp Range | 0 °C to 55 °C |
| Power Requirements | +3.3 VDC -- 940 mA |
| Bus Power Required | +8 V To +18 V |
| Dimensions | 4.2 in. x 6.6 in. (10.67 cm x 16.76 cm) |
| Weight | 3.6 oz. (102 g) |
| Software Driver | NI‑XNET, NI-CAN |
| Warranty | 2-3 Year Warranty |
| PCI-8516 Manual | User Manual and Maintenance Manual Available for Download |
| Price | Contact a sales representative for a quote. |
