National Instruments PCI-232I/4 Serial Interface Board
The PCI-232I/4 is a Serial Interface Board developed by National Instruments. The PCI-232I/4 is available under part number 777854-04. The PCI-232I/4 board is used to communicate with other instruments via serial ports. The PCI-232I/4 interface board incorporates four connections on a single panel. 10-position modular jacks are used for this purpose. Conventional DB-9 or DB-25 connectors can also be used with this Serial Interface Board with the use of optional cable accessories. The PCI-232I/4 works on the principle of RS-232 serial protocols. The PCI-232I/4 board can be used to transfer data up to a distance of 50 ft without any interruption or data loss.
The PCI-232I/4 Serial Interface Board supports the PCI bus. Optical isolation is a feature provided in the PCI-232I/4 board. It makes communication reliable in noisy systems. The required power of the Serial Interface Board is +5 VDC. The typical current at +5 VDC is 500 mA. The PCI-232I/4 can bear a maximum current of 750 mA without any damage. This Serial Interface Board also features ESD protection on a data line up to +15 kV. The PCI-232I/4 can transfer data at a maximum speed of 115.2 kb/sec. A FIFO buffer is also provided in the PCI-232I/4 board with a memory size of 64 B.
The supported software for the PCI-232I/4 is NI-Serial. The NI-serial software is supported for Windows 8, 7, Vista, and XP. The NI-serial software comes with a built-in device driver. The NI-serial software also includes diagnostic and configuration utilities.
PCI-232I/4 Obsolete Status has been announced by National Instruments, but will still be available for purchase and repairs by Apex Waves.
| Model | PCI-232I/4 |
|---|---|
| Manufacturer | National Instruments |
| Part Number | 777854-04 |
| Type | Serial Interface |
| Ports | 4 |
| I/O Connector | 10-position modular jack (10P10C) |
| FIFO Size | 64 Bytes |
| Dimensions | 4.2 x 6.9 in. |
| Driver Software | NI-Serial |
| Warranty | 2-3 Year Warranty |
| PCI-232I/4 Manual | User Manual and Maintenance Manual Available for Download |
| Price | Contact a sales representative for a quote. |
Associated part numbers for PCI-232I-4:
National Instruments PCI-232I/4 Frequently Asked Questions
Question: Which type of connector does the NI PCI-232I/4 have?
Answer: The NI PCI-232I/4 has a 10P10C connector.
Question: What is the power requirement of the PCI-232I/4?
Answer: The power requirement of the PCI-232I/4 is 500 mA typical and 750 mA maximum for +5 VDC.
Question: Which driver software is supported by the NI PCI-232I/4?
Answer: NI-Serial driver software is supported by the NI PCI-232I/4.
Question: Which signals are compatible with the PCI-232I/4?
Answer: CTS, RXD, RTS, GND, and TXD signals are compatible with the PCI-232I/4.
