National Instruments SCXI-1000 Chassis

The NI SCXI 1000 (Part Numbers: 776570-01, 776570-02, 776570-03, 776570-04, 776570-05, 776570-06, 776570-07, 778570-01, 778570-04, 776570-09, 776570-10 ) is a durable, low-noise chassis for SCXI modules, which deals with all the planning, initiation, and routing of signals between different modules and the SCXI modules. For bigger frameworks or future developments, the user can interface a maximum of eight SCXI 1000 chassis with a solitary gadget or multi-function I/O modules for multi-channel applications. The SCXI-1000 offers seven diverse power alternatives that adjust to each country’s electricity requirements and can be reconfigured for use in different countries. The chassis can work with line voltages of 100, 120, 220, and 240 VAC. The voltage tumbler in the power passage module decides the voltage for which the chassis is arranged.

In multiplexed mode, Analog Input (AI) channels are multiplexed into one module output, so the cabled E/M Series DAQ gadget approaches the multiplexed output of the module and the outputs of all other multiplexed modules in the case. In parallel mode, the user requires a different E/M Series DAQ gadget for every module to send each of its output channels specifically to a different AI channel of the E/M Series DAQ gadget associated with the module.

The user can arrange the SCXI-1000 for one of 32 distinct addresses. Therefore, several NI SCXI-1000 can be associated to the same control source (the five switches on the front board of Slot 0 decide the frame address). Switches one through five represent values 1, 2, 4, 8, and 16 when set to the ON position. When it is set to the OFF position, their esteem is zero. The chassis address is the whole of the switch esteems. The NI device weighs 10 oz, and measures 9.8 x 7.7 x 7.0 in. in physical dimensions. It dissipates power at 7 W per slot, has a recommended operating temperature range of 0 to 50 °C, and a storage temperature range of –20 to 70 °C.

The status of the SCXI-1000 is now Obsolete and it is no longer available from the manufacturer National Instruments, but the chassis will still be available in perpetuity for both purchase and repairs with Apex Waves.

ModelSCXI-1000
ManufacturerNational Instruments
Part Numbers

776570-01, 776570-02, 776570-03, 776570-04,
776570-05, 776570-06, 776570-07, 778570-01,
778570-04, 776570-09, 776570-10

SeriesSCXI Series
TypeChassis
Slots4
Power Dissipation7 W per Slot
Dimensions9.8 by 7.7 by 7.0 in.
Weight8 lb, 10 oz.
WarrantyThree Year Warranty
SCXI-1000 ManualUser Manual and Maintenance Manual Available for Download
PriceRequest a Quote for More Info

Associated part numbers for SCXI-1000:

National Instruments SCXI-1000 Frequently Asked Questions



Question: What is the difference between the part numbers for the SCXI 1000?

Answer: The various part numbers have different power options: part number 776570-01 with U.S. 120 VAC, part number 776570-02 with Swiss 220 VAC, part number 776570-03 with Australian 240 VAC, part number 776570-04 with Universal Euro 240 VAC, part number 776570-05 with North American 240 VAC, part number 776570-06 with United Kingdom 240 VAC, part number 776570-07 with Japanese 100 VAC, part number 776570-09 - with Korea 220V, part number 776570-10 with China 220V, part number 778570-01 with a USB HVAB option, and 120V, and part number 778570-04 with a USB HVAB option and EURO 240V.



Question: What are the NI SCXI-1000 drivers called?

Answer: The drivers used by the chassis are NI-SWITCH and NI-DAQ 7.



Question: What is the maximum operating current of the SCXI-1000?

Answer: The maximum operating current is 0.6 A at 100 VAC, 0.5 A at 120 VAC, or 0.25 A at 220 or 240 VAC.



Question: What happens if I remove a module while the NI SCXI-1000 Chassis is powered on?

Answer: If a module is removed while the chassis is powered on, it may result in blowing a fuse because the SCXI modules are not hot swappable.
