National Instruments - SCXI - 776572-95 - Wiring
776572-95 New
776572-95 Refurbished
❮ ❯

Actual item may vary if no part number is provided on quote request.

National Instruments - SCXI - 776572-95
National Instruments - SCXI - 776572-95 - Wiring
776572-95 New
776572-95 Refurbished

✔ 2 Year Warranty Included

✔ Free Ground Shipping

✔ NIST Calibration Available

Please fill out the form below to send in your quote request and a representative will contact you with a formal quote. View blog post on Model Name vs. Part Numbers

+Add more parts

Avg. Response Time: 15 min

Prefer to send a text message?

Text your name, e-mail, and parts to quote to:   1-919-809-5227

National Instruments 776572-95 RF Multiplexer Switch Module

The National Instruments 776572-95 (Model Name: SCXI-1195) is a high frequency unterminated multiplexing switch module. This model is specifically designed for routing high frequency signals in automated test equipment (ATE) systems. This module provides an efficient and reliable switching solution for applications requiring minimal signal loss and excellent signal integrity. Its primary advantage lies in low insertion loss which ensures signal integrity during routing.

The 776572-95 module includes a maximum switching voltage of 30 V and a maximum switching current of 0.5 A per channel which ensures safe operation within these limits. The module can handle a maximum carry current of 0.5 A per channel and up to 10 W of RF power. This makes it suitable for handling typical high frequency signal demands without compromising performance or safety.

The multiplexer switch module features a nominal characteristic impedance of 50 Ω. The module offers an insertion loss of less than 2.8 dB up to 5 GHz. Its Voltage Standing Wave Ratio (VSWR) is rated under 1.85 for frequencies up to 5 GHz. This guarantees excellent impedance matching and minimal signal reflection. The module also boasts impressive isolation figures providing over 30 dB of isolation at 5 GHz which minimizes interference between channels and enhances signal clarity.

The 776572-95 switch module is engineered for dynamic performance with a maximum scan rate of 45 channels per second. The module's mechanical and electrical relay life spans are 1 million and 300,000 cycles respectively. It also features a trigger system that uses SCXI trigger lines 0–7. This supports flexible timing and synchronization with other system components.

The NI 776572-95 module features electromechanical latching relays and comes with 20 SMA jacks for input/output connections. It has modest power requirements, drawing 50 mA at +5 VDC and up to 120 mA at other voltage levels. Its compact design (19.8 × 3.0 × 17.3 cm) and weight of 737 g make it suitable for rack mounted applications without adding significant bulk. It complies with several safety standards (IEC 61010-1, UL 61010-1 and CSA 61010-1). This ensures it meets the safety requirements for electrical and laboratory use.


Part Number776572-95
Model NameSCXI-1195
Part TypeRF Multiplexer Switch Module
Maximum Switching Voltage30 V
Maximum Switching Current0.5 A
Maximum Carry Current0.5 A
Maximum RF Power10 W
Dimensions19.8 × 3.0 × 17.3 cm (7.8 × 1.2 × 6.8 in.)
Weight737 g (1 lb 10 oz)
Warranty2 - 3 years
