National Instruments PXIe-2725 PXI Programmable Resistor Module
The PXIe‑2725 (Part Number: 781986-25) is a Programmable Resistor Module that imitates the behavior of resistance-based inputs and outputs such as potentiometers, resistance temperature detectors (RTDs), voltage dividers, and bridge elements. The NI PXIe‑2725 is programmed to control a series of relays to vary the resistance across each channel of an I/O connector. This module comes with software that provides a simple user interface that accepts inputs in units of temperature or resistance, configuring the resistance across each channel.
The PXIe‑2725 is ideal for simulating environmental conditions in hardwareâ€inâ€theâ€loop (HIL) validation. This Programmable Resistor Module uses a 37â€pin Dâ€SUB connector on the front panel, as well as a 2x2 Microâ€Fit connector for easy connection to a PXI Digital Multimeter (DMM). This module has 18 channels with a maximum voltage of 60 VDC, 30 VACrms, CAT I1 (channel-to-channel) and 60 VDC, 30 VACrms, CAT I1 (channel-to-ground). The maximum current is 0.3 A (per channel) and the maximum power is 0.25 W (per channel). This module has resolution in 1 Ω steps; the range is between 1 Ω to 255 Ω (per channel).
For channel set between 20 Ω and 64 Ω, the channel accuracy is <5.0% and <2.0% for channel set between 64 Ω and 255 Ω. The dimensions (L × W × H) of the NI PXIe‑2725 are 21.6 × 2.0 × 13.0 cm (8.5 × 0.8 × 5.1 in.) and the module weighs 323 g (11.3 oz).
| Model | PXIe-2725 |
|---|---|
| Part Number | 781986-25 |
| Manufacturer | National Instruments |
| Type | PXI Programmable Resistor Module |
| Channels | 18 |
| Maximum Resistance | 255 Ohm |
| Resistance Resolution | 1 Ohm |
| Dimensions | 8.5 x 0.8 x 5.1 in. |
| Weight | 11.3 oz. |
| Warranty | 2-3 Year Warranty |
| PXIe-2725 Manual | User Manual and Maintenance Manual Available for Download |
| Price | Contact a sales representative for a quote. |
Associated part numbers for PXIe-2725:
National Instruments PXIe-2725 Frequently Asked Questions
Question: What type of relays are in the PXIe-2725?
Answer: The PXIe-2725 has reed relays.
Question: What is the resolution of the NI PXIe-2725?
Answer: The NI PXIe-2725 has 8 bits resolution.
Question: What type of DMM port does the PXIe-2725 have?
Answer: The PXIe-2725 has a 2 x 2 Micro-Fit connector for the DMM port.
Question: What is the relay operating/release time on the PXIe-2725?
Answer: On the PXIe-2725, the relay operating/release time is 250 μs.
