National Instruments PXI-1025 MegaPAC Chassis
The National Instruments PXI-1025 MegaPAC Chassis is a unique, portable PXI computer platform designed with expandability, modularity, and the utility needed for challenging measurement, instrumentation, testing, and communication applications. This model comes equipped with 8 expansions slots and offers 350W peak power. The NI PXI-1025 MegaPAC was developed jointly by Dolch Computer Systems and National Instruments.
This portable computer platform is an ideal solution for mobile technicians as it comes in a rugged chassis with an SVGA 10.4" color, active matrix LCD, as well as a fold down/removable keyboard. The NI PXI-1025 has a universal, 350W AC power supply and can be used with an external AC to DC power inverter where only DC power is available. The temperature sensor-based cooling system on this model controls and regulates the speed of integrated high-speed cooling fans to keep the operating temperatures at optimum levels while saving power.
The National Instruments PXI-1025 accepts all modules designed per PICMG 2.0 specifications. To provide the user with an ultimate interference experience, this model has a pointing stick style device and a Notebook Style 85 Key Keyboard. As far as its physical characteristic is concerned, the NI PXI-1025 weighs around 11.4 kg. and its dimensions are 16 X 18.1 X 8.4 in. This model is considered a viable solution for portable applications because it comes with a carrying handle. To tilt the chassis, the carrying handle doubles when used as a bench-top rest. The mounting points available on the PXI-1025 can also be used in different mounting configurations.
| Model | PXI-1025 |
|---|---|
| Manufacturer | National Instruments |
| Type | MegaPAC Chassis |
| Display | 10.4 in. color TFT, SVGA |
| PXI Slots | 8 |
| Input Voltage | 90 to 265 VAC Universal |
| MTBF | 17,000 hours |
| Dimensions | 16 x 18.1 x 8.4 in. |
| Weight | 25 lbs. |
| Warranty | 2-3 Year Warranty |
| PXI-1025 Manual | User Manual and Maintenance Manual Available for Download |
| Price | Contact a sales representative for a quote. |
Associated part numbers for PXI-1025:
National Instruments PXI-1025 Frequently Asked Questions
Question: What type of pointing device does the PXI-1025 have?
Answer: The PXI-1025 has a pointing stick style device, integrated with a keyboard and two buttons.
Question: What is the maximum usable output power for the NI PXI-1025?
Answer: The maximum usable output power for the NI PXI-1025 is 350 W.
Question: Which features help the PXI 1025 be easily transported?
Answer: The PXI 1025 can be easily transported because of the carrying handle and tilt stand, the keyboard which can be folded down and/or removed, the large display screen for easy viewing, and durability of the Chassis.
Question: What type of modules does the PXI-1025 accept?
Answer: The PXI-1025 accepts modules compliant with CompactPCI, PICMG 2.0 specification.
