National Instruments PCI-8511 CAN Interface Device
The National Instruments PCI-8511 (Part Number: 780682-01) functions admirably in functions that need rapid ongoing control for many coverings and CAN signals, like the case of the equipment on top of it reproduction, quick prototyping of control, bus checking, automation control, and more. This model has an NI-XNET driver that controls the DMA and allows the inner processor to exchange outlines and CAN signals between the program and the interface without intruding into the CPU.
The NI-XNET interface unites the execution related with low-level microcontroller programming and the intensity of Windows and LabVIEW Real-Time OS advancement. The patent-pending NI-XNET gadget driven DMA motor decreases framework idleness for PC-based CAN, LIN, and FlexRay interfaces, from milliseconds to microseconds.
The driver-level signal Database motor and packaged NI-XNET utilities decreases tedious casing-to-flag interpretation while keeping up top execution. Support for industry-standard CAN, LIN, and FlexRay flag database positions, including FIBEX, CANdb (.DBC), LDF, and NI-CAN NCD, rearranges NI-XNET reconciliation into implanted system outline work processes. With equipment quickened outlines, NI-XNET gadgets offload dull preparing from the host framework, leaving more CPU time for executing models and performing different assignments. NI-XNET LIN gadgets likewise offer equipment planned booking, leaving more CPU time for different undertakings. NI RTSI synchronization bolster empowers NI-XNET interfaces to coordinate and synchronize with other NI items, including information securing, PXI secluded instrumentation, vision, and movement.
| Model | PCI-8511 |
|---|---|
| Manufacturer | National Instruments |
| Part Number | 780682-01 |
| Type | CAN Interface Device |
| Ports | 1 |
| Transceiver | NXP TJA1054A or TJA1055T |
| CAN Physical Layer | Low-Speed/Fault-Tolerant CAN |
| Maximum Baud Rate | 125 Kb/sec |
| Minimum Baud Rate | 10 Kbps |
| Trigger Lines | 7 Input/Output |
| Clock Lines | 1 Input/Output |
| I/O Connector | 9-pin Male D-SUB For Each Port |
| I/O Compatibility | TTL |
| Power Requirements | +5 VDC, +3.3 VDC -- 640 mA, 940 mA |
| Dimensions | 4.2 in. x 6.6 in. |
| Weight | 0.22 lb. |
| Software Driver | NI‑XNET |
| Warranty | 2-3 Year Warranty |
| PCI-8511 Manual | User Manual and Maintenance Manual Available for Download |
| Price | Contact a sales representative for a quote. |
Associated part numbers for PCI-8511:
PCI-8511 PDF Manuals
NI-XNET-HARDWARE-AND-SOFTWARE-MANUAL.PDF
NI-XNET-HARDWARE-AND-SOFTWARE-USER-MANUAL-AND-SPECIFICATIONS.PDF
Driver Downloads for PCI-8511
