National Instruments RMC-8357 External Controller for PXI
Featured with an Eight-Core processor and 32 GB RAM, the NI RMC-8357 (Part Numbers: 785673-01 and 785672-01) is a 1U, 2.1 GHz rugged External Controller for remote controlling of PXI Chassis. The CPU incorporated in this External Controller for PXI is an Intel Xeon E5-2620 v4 CPU. The RMC-8357 offers the capabilities of an advanced PC in a 1U rack-mountable form factor. The NI RMC-8357 comes equipped with 2 serial ports, 1 DVI port, 2 USB 2.0 ports, 4 USB 3.0 ports, and 1 VGA port. This External Controller comes with 1 TB SSD and supports as many as four 2.5 in drives.
The mainboard of the RMC-8357 has an LGA 2011 socket and Xeon E5-2620 v4 chipset. The NI RMC-8357 has four SATA III ports and eight 240-pin memory slots. The CPU in this External Controller for PXI has a clock speed of 2.10 GHz and can operate at a maximum turbo frequency of 3.0 GHz. In the standard configuration, the NI RMC-8357 is offered with 32 gigabytes of installed memory. The National Instruments RMC-8357 External Controller for PXI is designed with 1U height.
This External Controller for PXI has various power management features, including WOL, ACPM/ACPI power management, and power-on-mode. You can stay updated with the operating status of this the RMC-8357 through various LED indicators. The NI RMC-8357 External Controller for PXI has multiple system management features, including fan speed control and CPU thermal strip support. This External PXI Controller supports redundant power supplies and designed for high-reliability measurement and test applications.
| Model | RMC-8357 |
|---|---|
| Manufacturer | National Instruments |
| Part Numbers | 785673-01 and 785672-01 |
| Type | External Controller for PXI |
| CPU | Xeon E5-2620 v4 Eight Core |
| Clock Speed | 2.10 GHz |
| Standard Memory | 32 GB (4 × 8 GB), DDR4 SDRAM |
| Height | 1U |
| Dimensions | 17.0 in. x 21.2 in. (W x D) |
| Weight | 17.8 lbs. |
| Warranty | 2-3 Year Warranty |
| RMC-8357 Manual | User Manual and Maintenance Manual Available for Download |
| Price | Contact a sales representative for a quote. |
