National Instruments PXIe-6536 PXI Digital I/O Module

The 32 Channel, 25 MHz, 100 MB/s PXIe-6536 (Part Number: 779988-01) Digital I/O Module utilizes the PXI trigger bus or RTSI bus to send and get clock and trigger signals to and from other NI PXIe-6536 modules in a framework. With these capacities, the user can make synchronized frameworks with expansive quantities of digital I/O lines. The user can additionally utilize the PXIe 6536 with an NI link connector to associate with existing NI PXIe 6536 applications. In contrast with digital legacy I/O boards, the PXIe-6536 device has enhanced signal quality.

The PXIe 6536 will allow the user to create and acquire bigger digital waveforms with PCI Express fast gadgets, utilizing the perfect, minimal effort. The National Instruments PXIe-6536 Digital I/O Module streams data continuously at rates as high as 200 MB/s. This module incorporates NI RAID arrays and controllers, which can be used for applications requiring high speeds and quick streaming abilities. These applications include: LCD testing, wireless protocols, ADC/DAC interfacing, or digital pattern capture.

This Digital I/O Module can be used with SCC, which is a front-end signal molding framework module data acquisition gadget. An SCC framework is comprised of a protected bus that holds as many as 20 single or double channel SCC modules for molding thermocouples and different transducers. SCC is intended for little estimation frameworks where the user requires just a couple of channels of each signal, or for versatile applications. SCC frameworks additionally offer the most extensive and adaptable signal network alternatives.

ModelPXIe-6536
Part Number779988-01
ManufacturerNational Instruments
TypePXI Digital I/O Module
Bidirectional Digital Channels32
Digital Input Voltage Range-1 V to 6 V
Output Voltage Range0 V to 5 V
Dimensions8.42 x 0.79 x 5.14 in.
Weight5.1 oz.
Warranty2-3 Year Warranty
PXIe-6536 ManualUser Manual and Maintenance Manual Available for Download
PriceContact a sales representative for a quote.

Associated part numbers for PXIe-6536:

National Instruments PXIe-6536 Frequently Asked Questions



Question: What is the single-ended digital I/O channel current drive for the PXIe-6536?



Answer: The single-ended digital I/O channel current drive for the PXIe-6536 is 32 mA.



Question: What is the maximum clock rate for the NI PXIe-6536?



Answer: The NI PXIe-6536 has a maximum clock rate of 25 MHz.



Question: What is the maximum data channel toggle rate for the PXIe 6536?



Answer: The maximum data channel toggle rate for the PXIe 6536 is 12.5 MHz.



Question: Which type of signals does the NI PXIe-6536 have?



Answer: The NI PXIe-6536 has single-ended signals.
