National Instruments cRIO-9033 CompactRIO Controller

The cRIO-9033 is an embedded CompactRIO controller by National Instruments. The part number of the cRIO-9033 is 783452-01. This module is designed for monitoring applications where advanced user control is required. The cRIO-9033 can run the Linux RT operating system. This module also features a user interface capability. This feature allows the user to add an HMI by adding a monitor via the mini DisplayPort. The cRIO-9033 can be interfaced with a host network or computer, and startup options are configurable. The USB device port or Ethernet port is used for this purpose.

The NI cRIO-9033 CompactRIO Controller has a dual-core processor with a clock frequency of 1.33 GHz. For USB connectivity, the controller provides one USB 2.0 device port (480 Mbps) for configuration and console access and two USB 2.0 host ports (480 Mbps) for peripheral devices such as keyboards, storage drives, or cameras. The serial port's maximum baud rate is up to 230,400 bps. The integrated mini DisplayPort supports display resolutions up to 2560 × 1600 at 60 Hz, enabling direct user interface connections.

The cRIO-9033 CompactRIO Controller is used for waveform acquisition, high-speed control, timing and triggering tasks, and Ethernet-based synchronization. This high-performance controller is also used for communication and synchronization over Ethernet networks and can be used to design complex monitoring and control systems.

Model	cRIO-9033
Manufacturer	National Instruments
Part Number	783452-01
Type	CompactRIO Controller
CPU	Intel Atom E3825
Operating System	Linux Real-Time
FPGA	Kintex-7 160T
DRAM	1 GB
Ethernet Ports	2
Dimensions	8.64 x 3.47 x 4.30 in. (approximately)
Weight	3 lbs., 15 oz. (approximately)
Warranty	2-3 Year Warranty
cRIO-9033 Manual	User Manual and Maintenance Manual Available for Download
Price	Request a quote

Associated part numbers for cRIO-9033:

National Instruments cRIO-9033 Frequently Asked Questions

Question: How can I check if my cRIO-9033 is connected via a LAN or USB cable?

Answer: In NI MAX (Measurement & Automation Explorer), the controller will list connection type: Ethernet (LAN) or USB (via NI-USB-RT interface).

Question: Why am I getting an error message with the NI cRIO-9033 using FPT to log more than 32 files? It says that FTP has been aborted by the peer.

Answer: If you’re getting an error message when logging files to your CompactRIO controller, you are running into an issue that is specific to LabVIEW RT 2017. Edit the /etc/vsftpd.conf file by inserting the following setting: seccomp_sandbox=NO. This only applies to LabVIEW Real-Time 2017. Later versions may not require this fix.

Question: How do I find the cRIO-9033 on my network using DHCP?

Answer: To find the cRIO controller on a network using DHCP, first disable any secondary network interfaces on your computer. Make sure your anti-virus or firewall software allows connections and use the firewall software manual for instructions on configuration. Launch MAX, then find your system.
