cRIO-9014 NI CompactRIO Controller | In Stock Ships Today | Image

❮ ❯

Actual item may vary if no part number is provided on quote request.

✔ 2 Year Warranty Included

✔ Free Ground Shipping

✔ NIST Calibration Available

Anonymous Verified Buyer

" Very responsive and helpful, competitive pricing. Good source! "

July 2025

Andrew Gar**** Verified Buyer

" Amazing to work with and had my order within 1 week after purchasing with all NI certs and data that were needed. "

March 2025

Said Sai**** Verified Buyer

" Competent contact for highly specialized components. The support team is very knowledgeable. Many thanks for the help and the fast shipping! "

January 2025

Bob C**** Verified Buyer

" Jason was able to get our emergency situation taken care of quickly and professionally. "

May 2025

Gregg Flecki**** Verified Buyer

" Great service and great products. This is my 2nd time using Apex Waves, truly impressed. "

January 2025

Please fill out the form below to send in your quote request and a representative will contact you with a formal quote. View blog post on Model Name vs. Part Numbers

Name*

Email Address*

Model Name

Part Number

Qty

+Add more parts

Additional Info - Calibration, Expedited Shipping or Other Notes

Avg. Response Time: 15 min

Prefer to send a text message?

Text your name, e-mail, and parts to quote to: 1-919-809-5227

Carol Zimme**** Verified Buyer

" Very responsive and helpful, competitive pricing. Good source! "

July 2025

Andrew Gar**** Verified Buyer

" Amazing to work with and had my order within 1 week after purchasing with all NI certs and data that were needed. "

March 2025

Said Sai**** Verified Buyer

" Competent contact for highly specialized components. The support team is very knowledgeable. Many thanks for the help and the fast shipping! "

January 2025

Bob C**** Verified Buyer

" Jason was able to get our emergency situation taken care of quickly and professionally. "

May 2025

Gregg Flecki**** Verified Buyer

" Great service and great products. This is my 2nd time using Apex Waves, truly impressed. "

January 2025

National Instruments cRIO-9014 CompactRIO Controller

The cRIO-9014 (part numbers: 779564-01 and 779564-02) is a CompactRIO controller developed by National Instruments. This model is used to control and monitor C Series applications. The cRIO-9014 incorporates several ports for various connections. These ports include USB, Ethernet, and an RS-232 serial terminal. The Controller cannot be connected with the C Series devices directly because no such slot is available. However, the NI cRIO-9014 can be interfaced with the C Series device through an extension, a compatible CompactRIO chassis.

The cRIO-9014 CompactRIO Controller is a rugged device designed to withstand harsh environments. The processor of the cRIO-9014 has a PowerPC-type core, and the frequency of the processor is 400 MHz. The supported networks for the interface are 10Base-T and 100Base-TX Ethernet. The controller can communicate at the rates of 10 Mbps per second and 100 Mbps per second. The cRIO-9014 features an RS-232 terminal for serial communication. The serial port supports a baud rate up to 115,200 bps. This model also has a USB port, which can sustain up to 500 mA current. The data can be transferred at a maximum speed of 12 Mb per second through the USB port. There is a nonvolatile memory of 2 GB. The controller also has a dynamic RAM with a memory of 128 MB.

The cRIO-9014 CompactRIO Controller features an SMB digital I/O connector with an input voltage in the range of -500 mV to 5.5 V. The supported logic level is 3.3 V. This model supports a CMOS-type driver. The input capacitance is 2.5 pF, and the maximum power consumed by the cRIO-9014 is 20 W. It has a recommended operating temperature of -40 °C to 70 °C. The device weighs 17.2 oz., and its dimensions are 3.6 x 3.0 x 3.5 in.

National Instruments has declared the status of the cRIO-9014 to be obsolete, but the CompactRIO controller will remain available for purchase and repair services with Apex Waves in perpetuity.

Model	cRIO-9014
Manufacturer	National Instruments
Part Numbers	779564-01, 779564-02
Type	CompactRIO Controller
Memory	2 GB (nonvolatile)
DRAM	128 MB
Maximum Data Rate	12 Mb/s
Dimensions	3.6 x 3.0 x 3.5 in.
Weight	17.2 oz.
Warranty	2-3 Year Warranty
cRIO-9014 Manual	User Manual and Maintenance Manual Available for Download
Price	Request a Quote

Associated part numbers for cRIO-9014:

National Instruments cRIO-9014 Frequently Asked Questions

Question: If I have the cRIO-9014 controller, how does it communicate with the MVI56 PDPMV1 through controller tags of 1756-L73?

Answer: The cRIO-9014 runs NI Real-Time, but it does not natively support PROFIBUS. Communication with a PROFIBUS network or a ControlLogix system (1756-L73) requires appropriate communication modules or external gateways.

Question: Does the NI cRIO-9014 have a USB host port?

Answer: Yes, the cRIO-9014 does include a USB host port.

Question: How does the CompactRIO Controller ensure reliability with its data logging?

Answer: The cRIO-9014 uses the NI Real-Time operating system, which provides reliable file handling for data logging. Proper programming practices are still required to ensure data integrity.
