E6630A Keysight Wireless Connectivity Test Set | Apex Waves | Image
E6630A Keysight Wireless Connectivity Test Set | Apex Waves | Image
E6630A New
E6630A Refurbished
❮ ❯

Actual item may vary if no part number is provided on quote request.

E6630A Keysight Wireless Connectivity Test Set | Apex Waves | Image
E6630A Keysight Wireless Connectivity Test Set | Apex Waves | Image
E6630A New
E6630A Refurbished

✔ 2 Year Warranty Included

✔ Free Ground Shipping

✔ NIST Calibration Available

Please fill out the form below to send in your quote request and a representative will contact you with a formal quote. View blog post on Model Name vs. Part Numbers

+Add more parts

Avg. Response Time: 15 min

Prefer to send a text message?

Text your name, e-mail, and parts to quote to:   1-919-809-5227

Keysight E6630A Wireless Connectivity Test Set

The E6630A is a Discontinued Wireless Connectivity Test Set manufactured by Agilent/HP/Keysight Technologies. The E6630A belongs to the X Series that is customized for high throughput tests. The E6630A is equipped with one or two transmitter receiver instruments. These instruments contain an RF analyzer and an RF source. The E6630A Wireless Connectivity Test Set is used in combination with the E66318A Multi-port Adaptor. The function of the E66318A Adaptor is to divide the RF downlink signal that comes from the E6630A. These signals are divided into 8 paths of RF output signals. These 8 output paths can be made active simultaneously. Alternatively, the user can also select some of these output paths for activation in whatever combinations the user requires.

Through a coupler, each one of the paths interfaces with the RFIO ports. This interference enables the RFIO ports to give the analyzer an uplink signal in the Keysight E6630A. The user can also bypass the coupler through a “high power output only” path. On the other hand, the RF’s downlink signal from the E6630A can also be sent to four GNSS outputs with the help of a four-way splitter.

Each instrument is displayed by an individual window of XSA when accessed on a monitor screen or the remote web desktop of the E6630A Wireless Connectivity Test Set. The window contains “left or right” identifiers so the user can recognize the TRX controlled by the window. A specific version of XSA firmware application is required to run the Keysight E6630A Wireless Connectivity Test Set.

ModelE6630A
ManufacturerKeysight Agilent HP
SeriesWireless Test Sets
TypeWireless Connectivity Test Set
Form FactorPXI
Bandwidth80 MHz/160 MHz
Frequency Range1.1 to 1.7 GHz, 2.4 to 2.5 GHz, 4.85 to 6.0 GHz
RFIO Ports8
GNSS Outputs4
Warranty2-3 Year Warranty
E6630A ManualUser Manual and Maintenance Manual Available for Download
PricingContact a Sales Representative for a quote.
