Keysight N2099A, 2 Output, 2-Slot, PXI Synthesizer
Rated 4.8/5 | 11 ratings
Actual item may vary if no part number is provided on quote request.
✔ 2 Year Warranty Included
✔ Free Ground Shipping
✔ NIST Calibration Available
Andrew Gar**** Verified Buyer
" Amazing to work with and had my order within 1 week after purchasing with all NI certs and data that were needed. "
March 2025
Said Sai**** Verified Buyer
" Competent contact for highly specialized components. The support team is very knowledgeable. Many thanks for the help and the fast shipping! "
January 2025
Bob C**** Verified Buyer
" Jason was able to get our emergency situation taken care of quickly and professionally. "
May 2025
Gregg Flecki**** Verified Buyer
" Great service and great products. This is my 2nd time using Apex Waves, truly impressed. "
January 2025
Carol Zimme**** Verified Buyer
" Very responsive and helpful, competitive pricing. Good source! "
July 2025
Andrew Gar**** Verified Buyer
" Amazing to work with and had my order within 1 week after purchasing with all NI certs and data that were needed. "
March 2025
Said Sai**** Verified Buyer
" Competent contact for highly specialized components. The support team is very knowledgeable. Many thanks for the help and the fast shipping! "
January 2025
Bob C**** Verified Buyer
" Jason was able to get our emergency situation taken care of quickly and professionally. "
May 2025
Gregg Flecki**** Verified Buyer
" Great service and great products. This is my 2nd time using Apex Waves, truly impressed. "
January 2025
Keysight N2099A PXI Synthesizer
The Keysight N2099A Synthesizer is the perfect clock source for the N2102B Pattern Generator or the N2101B Bit Error Ratio Tester. This PXI Synthesizer belongs to the Agilent PXIT family. The N2099A is a 2-slot module, which is tunable over a 2 GHz range and incorporates synchronous double RF yields. The N2099A has two frequency ranges available, which are between 4.25 and 11.5 GHz. This module can be used with ActiveX drivers for a simple software interface, as well as a graphical user interface. The ActiveX drivers enable programmability to any ActiveX compliant programming setting. ActiveX drivers can be utilized with LabVIEW, Visual C++, Excel, Visual Basic, and C#, along with a variety of other programming environments. The software features include a Windows application control panel and require VISA software by National Instruments.
The input of the Keysight N2099A can be affirmed utilizing the status call. This is a Boolean call. A genuine esteem indicates that the synthesizer has achieved the Blocked state. This implies the synthesizer is hindered at a specific frequency. It does not unequivocally show that it is hindered in the last mentioned rate, yet it is a generally excellent pointer. This model shows a secured status in the Control Panel when it effectively bolts to a frequency. If the bolted status is not shown, the yield is at an obscure flag. This can occur at the outskirt edges of the tuning range or if the wind stream in the undercarriage is not ideal.
| Model | N2099A |
|---|---|
| Manufacturer | Keysight Agilent HP |
| Type | PXI Synthesizer |
| Output Frequency | 5.25 and 10.5 GHz |
| Tuning Range | ±1.0 GHz |
| Switching Speed (100 MHz step) | 100 ms typical |
| Outputs | 2 |
| Size | 2-slot module |
| TCXO Output Frequency | 10 MHz |
| Warranty | 2-3 Year Warranty |
| N2099A Manual | User Manual and Maintenance Manual Available for Download |
| Price | Contact a sales representative for a quote. |
Associated part numbers for N2099A:
Keysight N2099A Frequently Asked Questions
Question: Which operating systems are compatible with the Keysight N2099A?
Answer: The Keysight N2099A can be used with Microsoft Windows XP and Windows 7 operating systems.
Question: What is the tuning range of the N2099A?
Answer: The tuning range of the N2099A is 2 GHz.
Question: Which options are available for the N2099A Synthesizer?
Answer: The N2099A Synthesizer has two options available: Option 052 for 4.25 GHz to 6.25 GHz frequency range and Option 105 for 9.5 GHz to 11.5 GHz frequency range.
