Keysight M9392A PXI Vector Signal Analyzer
The Keysight M9392A Vector Signal Analyzer can be combined with the M9018A 18-slot PXIe Chassis and the 89600 VSA software, which results in a complete microwave vector signal analyzer arrangement that empowers the investigation of multichannel, communications, radar, and aerospace signals from 50 MHz to 26.5 GHz with 250 MHz of bandwidth. This modular is recommended to be calibrated every year to maintain all measurements within the specifications.
The advanced downconversion calculation (DDC) in the FPGA of the M9202A IF digitizer improves simple execution for spurious free dynamic range, signal-to-noise ratio, and lessens information load time. With the PXI Express M9202A backplane association, the M9392A can enable the persistent transmission of information to a disk. The user can additionally utilize multichannel assessment if they insert two PXI Vector Signal Analyzers in a single chassis.
The Keysight M9392A Vector Signal Analyzer has many valuable features, including decreased development time due to the drivers, soft front panel, and programming examples available in software such as MATLAB, LabVIEW, LabWindows/CVI, etc. The examples provided can be edited with ease to swiftly be integrated into any measurement system. This versatile product can be used in many configurations, enabling the M9392A to suit many applications for a diverse range of users.
The soft front panel on the Agilent M9392A controls the PXI Vector Signal Analyzer by allowing the user to monitor and manage capacities, such as input frequency, power, transfer speed, and time interim settings, trigger capacity settings, marker show, frequency and time screen position, observing of equipment status, and transmission of information to record.
| Model | M9392A |
|---|---|
| Manufacturer | Keysight Agilent HP |
| Type | PXI Vector Signal Analyzer |
| Frequency Range | 50 MHz to 26.5 GHz |
| Sample Rate | 2 GS/s |
| Bandwidth | 250 MHz, ≥ 2.75 GHz |
| Resolution | 12-bit |
| Size | 7 or 8 slots-wide multiple modules |
| Weight | 8.5 lbs. |
| Warranty | 2-3 Year Warranty |
| M9392A Manual | User Manual and Maintenance Manual Available for Download |
| Price | Contact a sales representative for a quote. |
Associated part numbers for M9392A:
Keysight M9392A Frequently Asked Questions
Question: Which sweep trigger modes are available on the Agilent M9392A?
Answer: The Agilent M9392A has video trigger, free run, and external trigger sweep trigger modes.
Question: What is the total power of the Keysight M9392A?
Answer: The total power of the Keysight M9392A is 92.5 W, maximum.
Question: Which type of RF IN connectors are on the M9392A?
Answer: The M9392A has APC 3.5 (precision type) RF IN connectors.
