Keysight N5322A Extended Interface Module
The N5322A Extended Interface Module is manufactured by Agilent/HP/Keysight. The Keysight N5322A Extended Interface Module is used for PCIe ASPM (active state power management) testing. The N5322A Extended Interface Module offers the steadiest lock time of the industry through a protocol analyzer. Active state power management is the core strategy being used by industries for minimizing the consumption of power in electronic devices/modules.
Electronic devices are extensively used in cell phones and power-saving is of the utmost importance in cell phones. Active state power management is used to extend battery life in mobiles. Active state power management is also critical in data center devices. Electronic devices like servers, storage equipment, and networking devices need energy management. Taking into consideration the cost and environment aspects, the N5322A module has a crucial role to play.
The Keysight N5322A Extended Interface Module is specially designed to make testing for active state power management easy. The Keysight N5322A is used in combination with the Keysight N5306A Analyzer I/O Module to provide extended features for analysis. The N5322A Extended Interface Module has 16 LEDs per lane. These LEDs show the status of each lane. The N5322A module has three connectors: an REF clock input, an intermodule, and an analyzer probe. The Keysight N5322A Extended Interface Module operates within 0 to 55 °C temperature range. The environmental rating of the N5322A module is standard with a pollution degree of 2.
| Model | N5322A |
|---|---|
| Manufacturer | Keysight Agilent HP |
| Series | Protocol Analyzers and Exercisers |
| Type | Extended Interface Module |
| LEDs | 16 per lane LEDs and 2 status LEDs |
| Compatible Model | N5306A Analyzer I/O Moduule |
| Supported Probes | Gen2 probes, Midbus 2.0, slot interposer 2.0, and flying lead probe 2.0 |
| Warranty | 2-3 Year Warranty |
| N5322A Manual | User Manual and Maintenance Manual Available for Download |
| Pricing | Contact a Sales Representative for a quote. |
