Keysight M9203A PXIe High Speed Digitizer
The M9203A PXIe High Speed Digitizer is manufactured by Agilent/HP/Keysight. The Keysight M9203A PXIe High Speed Digitizer has a wide bandwidth and low noise levels, which makes the digitizer perfect for wireless communication, satellite, and radar communications. The Keysight M9203A PXIe High Speed Digitizer is perfectly suitable for applications that require wideband signals capturing with a high dynamic range. The Keysight M9203A has 12-bit resolution, is a dual-slot 3U, PXIe Digitizer. The wideband receiver of the Digitizer goes up to 3.2 GS/sec, along with a bandwidth of 2 GHz. The M9203A PXIe High Speed Digitizer possesses a maximum of 4 GB DDR3 memory.
The Keysight M9203A has the PXI Express form factor. The Keysight M9203A PXIe High Speed Digitizer is able to integrate with chassis slots for PXI Hybrid and PXIe. The M9203A is constructed to take advantage of the fast data interfaces. The compact package setup of PXI supports high performance. The Keysight M9203A PXIe High Speed Digitizer consists of a DPU (data processing unit); it is the main component of M9230A.
The data processing unit supports controlling the flow of data, signal processing (real-time), and functions of the module. This amazing functionality permits the reduction of data and storing of data to be taken at digitizer levels. This also helps reduce the transfer volume and increases the speed of analysis. The Keysight M9203A PXIe High Speed Digitizer can be utilized in LTE, 5G communications, advanced communications standard, and automated tests of semi-conductors.
| Model | M9203A |
|---|---|
| Manufacturer | Keysight Agilent HP |
| Series | High-Speed Digitizers |
| Type | PXIe High-Speed Digitizer/Wideband Digital Receiver |
| Channels | 2 |
| Coupling | DC |
| Resolution | 12 bits |
| Size | 3U/2-slot PXI Express Chassis slot compatibility |
| Dimensions | 7.3 x 5.11 x 1.6 in. |
| Weight | 2 lbs. |
| Warranty | 2-3 Year Warranty |
| M9203A Manual | User Manual and Maintenance Manual Available for Download |
| Pricing | Contact a Sales Representative for a quote. |
