Keysight M9048A PCIe Desktop Adapter
The M9048A PCIe Desktop Adapter is manufactured by Agilent/HP/Keysight. The Keysight M9048A is a remote PCIe Desktop Adapter for the AXIe and PXIe systems. The Keysight M9048A offers a link that is a high performance, between the AXIe or the PXIe chassis and the computer by plugging into the PCIe slot of the remote computer. The M9048A Desktop Adapter comes with clock isolation and a PCIe switch. The Keysight M9048A has a low-profile card format, can be used with low profile and standard PCI brackets, and offers x8 Gen2 cable link for PCIe.
The Keysight M9048A Desktop Adapter has a maximum of 4 GB/s data bandwidth. The Keysight M9048A is used to achieve fine performance and permanent connection of a single or multiple chassis with a remote computer, including PXIe and PCIe modules. The M9048A PCIe Desktop Adapter is an interface module that allows connection from the end-user’s computer to multiple chassis or the test systems of AXIe or PXIe.
The Keysight M9048A PCIe Desktop Adapter offers a single port (x8), Gen2 system that permits end-users to achieve high performance connections from their remote computer. The M9048A requires 7 Watts of power connection, operates within 0° C to 55° C temperature range, and up to 95% of relative humidity. The Keysight M9048A can be utilized with a passive cable with a maximum of two meters length. The M9048A PCIe Desktop Adapter supports Windows 7 and 10 (both 32 bit and 64 bit) operating systems.
| Model | M9048A |
|---|---|
| Manufacturer | Keysight Agilent HP |
| Series | AXIe Chassis and Controllers |
| Type | PCIe Desktop Adapter |
| Card Format | Low profile |
| PCIe Cable Link | x8, Gen 2 |
| Maximum Data BW | 4 GB/s |
| Cable Length | Up to 2-meter passive cable |
| Computer Slot Compatibility | x8 Gen 2 or Gen 3, x16 Gen 2 or Gen 3 |
| Cable Connectors | One x8 PCIe iPass |
| Power Consumption | 7 W (typical) 2.1 A at 3.3 V |
| Dimensions | 2.2 x 4.5 in. |
| Warranty | 2-3 Year Warranty |
| M9048A Manual | User Manual and Maintenance Manual Available for Download |
| Pricing | Contact a Sales Representative for a quote. |
