ADLINK PXIS-2506 3U PXI CompactPCI Chassis
The PXIS-2506 by ADLINK is a 6 slot 3U PXI CompactPCI chassis for industrial automation systems. It offers one system slot and five peripheral slots supporting PXI and CompactPCI modules. Each peripheral slot of PXIS-2506 routes PXI resources including 10 MHz clock triggers and local bus. Its conformance to PXI Specification revision 2.2 and CompactPCI standards ensures deterministic backplane communication reliability. The PXIS-2506 chassis integrates a PICMG 2-11 compliant 250 W CompactPCI power supply module. Its AC input supports 100 V AC to 240 V AC at 50/60 Hz. The total output power of 250 W delivers regulated +5, +3.3, +12, -12 V rails with high current capability sustain PXI controllers and power-hungry instrumentation payloads. Its front accessible modular power design simplifies field replacement and minimizes mean time to repair intervals.
The PXIS-2506 chassis comes with 2 x 80 mm x 80 mm x 25 mm fans and provide 47.2 CFM of airflow. Its filtered forced air path directs cooling uniformly across all card slots and power components. This thermal configuration maintains controlled internal temperatures for fully populated chassis under continuous industrial duty cycles. Its optimized airflow orientation supports horizontal bench operation and multiple wall mounted configurations without compromising cooling efficiency. The PXIS-2506 mechanical structure provides rigidity for transportation racks portable stations and fixed industrial cabinets. Its overall dimensions are 221 mm x 178 mm x 237 mm (8.70 in × 7.01 in × 9.33 in) excluding accessories, while its 4.5 kg (9.92 lbs.) chassis weight eases handling while preserving secure mounting on structural surfaces. A supplied wall mount kit supports bottom side or top orientations for flexible integration within enclosures to facilitate repeatable installation in diverse automation infrastructures.
The PXIS-2506 chassis operates in the thermal range up to 131°F in controlled industrial environments and its permissible operating humidity extends from 10% to 90% non-moist. Its specified shock resistance is 15 G peak and its electromagnetic emissions compliance with EN 55022 and FCC Class A enables deployment among sensitive equipment. Safety adherence of this chassis is EN 60950-1 and immunity compliance with EN 55024 fulfill regulatory expectations. Its grounding layout and shielding support signal integrity for high resolution synchronized data acquisition. The PXIS-2506 supports ADLINK PXI-3900 series system controllers forming deterministic platforms for test measurement and control.
| Model Name | PXIS-2506 |
|---|---|
| Manufacturer | ADLINK |
| Part Type | 3U PXI CompactPCI Chassis |
| Slots | 1 system slot + 5 PXI/CompactPCI peripheral slots |
| AC Input | 100–240 VAC, 50–60 Hz |
| DC Output | 250 W total |
| Fans | 2 × 80 mm × 80 mm × 25 mm ball-bearing fans |
| Airflow | 47.2 CFM each |
| Shock Resistance | 15 G peak-to-peak, 11 ms duration |
| Emission Compliance | EN 55022 / FCC Class A |
