Adlink PCIe-PXIe-8638 PCI Express to PXI Express Extension Kit
The Adlink PCIe-PXIe-8638 kit is an expansion kit that enables the easy integration and control of PXI Express modules installed in a PXI Express (PXIe) chassis through high-performance PCI Express technology. This kit provides data bandwidth of up to 4 GB/s using x8 Gen2 signaling, for fast and reliable communication between the host computer and the PXI modules. It ensures transparent hardware and software operation, allowing automatic detection of PXI modules without requiring additional drivers or software.
The kit contains a PCIe-8638 host adapter installed in the host PC, a high-quality PCIe x8 cable and a PXIe-8638 remote controller installed in a 3U (Eurocard) expansion module. The PCIe-PXIe-8638 supports up to a 5-meter cable length, providing flexibility in system design and deployment. To support multi-chassis extension applications, the PXIe-8638D and PXIe-8638P models are available with support for daisy-chain and star-chain topologies, respectively, to provide centralized or distributed control over multiple PXIe chassis.
Well-suited for more demanding applications, the PCIe-PXIe-8638 excels in such applications as testing in electronics manufacturing, high-density I/O systems, industrial automation, and military/aerospace. It is particularly suited for remote or harsh conditions that demand robust, reliable operation. Typical use would also include video capture and advanced industrial control systems where high-speed data transfer is critical.
This expansion kit complies with the PCI Express Base Specifications Revision 2.0 and the PXI-5 PXI Express Hardware Specification Revision 2.0, while offering compatibility with a range of hardware configurations due to design options in low-profile and standard-profile options. Operating; 0°C to 55°C; storage, -20°C to 70°C.
Variants of the PCIe-PXIe-8638 series are for single and multi-chassis configurations, including cabling options in both 2-meter and 5-meter lengths to meet a variety of operational needs. It is an extremely important solution, with its transparent, high-speed bus extension capability, that can easily increase control and scalability in their PXI Express-based systems.
| Model Name | PCIe-PXIe-8638 |
|---|---|
| Part Type | PCI Express to PXI Express Expansion Kit |
| Data Bandwidth | Up to 4GB/s with PCIe Gen2 x8 signaling |
| Connectivity | PCIe x8 cable (available in 2m or 5m lengths) |
| Supported Configurations | Single-chassis or multi-chassis with daisy-chain and star-chain options |
| Hardware Compliance | PCI Express Base Specifications Rev. 2.0; PXI-5 PXI Express Specification Rev. 2.0 |
| Temperature Range | Operating: 0°C to 55°C; Storage: -20°C to 70°C |
| Power Consumption | Typical: 4W; Maximum: 8W |
| Module Compatibility | Supports PXI Express modules installed in PXI Express chassis |
| Maximum Expansion Distance | Up to 5 meters between host PC and PXI Express chassis |
