ADLINK cPCI-7248 CompactPCI Digital I/O Card
The ADLINK cPCI-7248 CompactPCI 48-Channel Digital I/O Card is a digital input and output interface card designed for multiple industrial automation applications. The cPCI-7248 card offers 48 programmable I/O channels that allow flexible digital signal control and monitoring across diverse system configurations. The module features full 5 V TTL compatibility across all input and output channels. The cPCI-7248 card module uses Peripheral Interface (PPI) chips and each PPI provides three 8-bit ports as Port A, Port B and Port C. It includes programmable power-on states including pull-high, pull-low and floating modes by providing flexible signal initialization options. It also ensures precise voltage recognition with defined input high levels from 2 V to 5.25 V and input low levels from 0 V to 0.8 V.
The output characteristics of the CompactPCI 7248 card maintain a minimum output high voltage of 2.4 V and a maximum output low voltage of 0.5 V. It provides a strong driving capability with 15 mA source current and 24 mA sink current per channel by ensuring stable signal delivery to external devices. It also supports programmed I/O data transfer mode for efficient communication between the system CPU and the I/O interface. The ADLINK cPCI-7248 digital I/O card module comes with a single 100-pin SCSI-II female connector that allows organized cable management and secure signal interfacing. It works with consistent performance in operating temperatures from 0°C to 60°C and can be safely stored in environments ranging from -20°C to 80°C. The card tolerates a wide relative humidity range of 5% to 95% non-condensing that makes it suitable for use in diverse industrial setups.
The cPCI-7248 card operates with low power requirements by allowing efficient system installation in chassis-based automation systems. Its design emphasizes electrical stability and signal integrity which aids in reducing noise interference in control domains. The 48-Channel Digital I/O Card provides high-grade digital signal control. The specified dimensions of this cPCI card module are given with 160 mm x 100 mm (6.30 inches x 3.94 inches) for systems requiring optimized space utilization. This terminal board is provided with one DIN-rail mounting capability without cables for convenient installation within control panels and enclosures. It features a 32-bit timer that operates using a built-in 2 MHz internal clock.
| Model Name | cPCI-7248 |
|---|---|
| Manufacturer | ADLINK |
| Part Type | CompactPCI 48-Channel Digital I/O Card |
| Number of Channels | 48 |
| Operating Temperature | 0°C to 60°C |
| Sink Current | 24 mA per channel |
| Source Current | 15 mA |
| Dimensions | 160 mm × 100 mm (6.30 in × 3.94 in) |
| Timer | 32-bit |
| Clock | 2 MHz |
